The Develon DX140LCR Large Excavator is the ultimate solution for tight job sites.
With its reduced tail swing design and exceptional digging power, it’s perfect for contractors, utility workers, and civil engineers.
Available to buy or hire, it’s ready to meet your toughest challenges.
On busy job sites or in urban environments, limited space can make heavy equipment challenging to manoeuvre.
Standard excavators with larger tail swings can be cumbersome, risking site damage or reducing efficiency.
For contractors, utility workers, and civil engineers, finding the right equipment for these scenarios is critical.
The Develon DX140LCR Large Excavator is engineered with a reduced tail swing design, allowing operators to work confidently in confined areas.
Its compact frame doesn’t compromise on power or versatility, making it ideal for utility trenching, site prep, and urban construction projects.
Available for purchase or hire, it’s the machine you can count on for tight-access sites.
Ideal for confined spaces, offering powerful performance without sacrificing manoeuvrability.
Ensures precise operation for tasks that demand accuracy and control.
Ergonomically designed with climate control for maximum comfort during long workdays.
Durable construction reduces downtime and maintenance costs on tough job sites.
Compatible with a variety of tools to handle trenching, grading, and material handling.
Reduced tail swing design ensures easy manoeuvrability in confined spaces.
Advanced hydraulics provide smooth, precise control for any job.
Eco-friendly engine minimises fuel consumption without sacrificing power.
Ergonomic cab with climate control keeps operators focused and productive.
Compatible with a wide range of attachments for varied applications.
Durable construction ensures long-term performance on demanding job sites.
Manoeuvre easily without worrying about site damage.
Ensures precise and efficient operation for complex tasks.
Combines power with sustainability for lower operational costs.
Stay productive during long workdays with advanced controls and a spacious interior.
Expand your machine’s capabilities for various applications.
Designed to handle the toughest environments with minimal maintenance.
Model
Cummins QSB 4.5 Common Rail engine with direct fuel injection and electronic control, 4 valves per cylinder, vertical injectors, water cooled, turbo charged with air-to-air intercooler. The emission levels are well below the values required for phase III.
4
100 hp (81 kW) @ 2,000 rpm
458kgfm @ 1500rpm
4,500 cc
24 V / 4.5 kW
2 x 12 V / 100 Ah
Double element with auto dust evacuation
Noise levels comply with environmental regulations (dynamic values).
101 dB(A) (2000 / 14 / EC)
71 dB(A) (ISO 6396)
The heart of the system is the e-EPOSTM (Electronic Power Optimising System). It allows the efficiency of the system to be optimised for all working conditions and minimizes fuel consumption.
The new e-EPOS is connected to the engine electronic control via a data transfer link to harmonise the operation of the engine and hydraulics.
2 variable displacement axial piston pumps
Maximum flow: 2 x 114 l/min
Gear pump – max flow: 35 l/min
Boom / Arm / Bucket –
Travel – 357 kgf/cm2
Swing – 275 kgf/cm2
The piston rods and cylinder bodies are made of high-strength steel. A shock absorbing mechanism is fitted in all cylinders to ensure shock free operation and extend piston life.
Boom
2
110 x 75 x 1,085mm
Arm
1
115 x 80 x 1,108mm
Bucket
1
100 x 70 x 900mm
Upper rollers: 1
Lower rollers: 7
Shoes: 46
Total length of track: 3,755mm
0 to 10.7 rpm
Each track is driven by an independent axial piston motor through a planetary reduction gearbox.
Two levers with control pedals guarantee smooth travel with counterrotation on demand.
4.7 / 3.0km/h
12,500 kg
35˚/ 70%
234 l
18 l
11 l
3.8 l
Final drive (each)
3 l
Hydraulic system
133 l
Hydraulic tank
93.5 l
Undercarriage
Its reduced tail swing design allows for efficient operation in tight areas.
Ideal for utility work, urban construction, and civil engineering projects.
Yes, Delecca’s offers flexible hire options to fit your project’s needs.
Compatible with a variety of tools, including buckets, hammers, and grapples.
Yes, its eco-friendly engine ensures cost-effective operation.
It offers a maximum digging depth of 5.5 metres.
Yes, all Develon machines come with a standard warranty package.
Delecca’s provides flexible financing solutions for your convenience.
Call us at 1300 77 88 26 or Book a Demo Online.
The Develon DX140LCR Large Excavator combines compact design with powerful performance to handle the toughest jobs in confined spaces. Available to buy or hire, it’s the perfect machine for your next project.
Call 1300 77 88 26 or explore the DX140LCR today!
