Bobcat E35 Mini Excavator
Dig with greater confidence with the Bobcat E35 mini excavator. A favourite in its class, it excels on space-constrained jobsites. Push your productivity to the next level.
Next level productivity
The mini excavator that can handle your tough jobs
The Bobcat E35 mini excavator is perfect for tight spaces. It has the power and performance to get the job done quickly and easily.
You’ll appreciate its comfortable controls and easy-to-use features. And because it’s so versatile, you can use it for a variety of applications – from light excavation to backfilling and grading.
Performance, durability and versatility
The zero-tail-swing design provides an increased amount of operator flexibility, while also reducing potential for damage to the machine and surrounding property.
The Bobcat E35 mini excavator is a high-quality workhorse that will never let you down. With low effort joysticks and excellent ride quality, this machine has been designed to make your day as easy as possible while still being efficient.
Optional features that will boost your productivity include the angle blade, long arm or clamp-ready extendable arm, clamp diverter valve, a 7-inch touch display screen and rear-view camera.
Bobcat E35 Mini Excavator Specifications
Overview
Operating weight
3,800kg
Tail swing type
Zero tail swing
Horsepower
18.5kW (24.8hp)
Width
1,753mm
Bucket Digging Force
30,995Nm
Maximum Reach at Ground Level
5.8m
Engine
Emissions Tier (EPA)
Tier 4
Engine Fuel
Diesel
Maximum Governed RPM
2,200rpm
Horsepower
18.5kW (24.8hp)
Turbocharged Engine
No
Optional Turbocharged Engine
No
Performance
Operating Weight
3,800kg
Weight Class
3.5t
Travel Speed – High
4.7km/h
Travel Speed – Low
2.6km/h
Arm Digging Force
20,413Nm
Bucket Digging Force
30,995Nm
Lift Radius
2,997mm
Boom Swing – Left
75°
Boom Swing – Right
55°
Maximum Dig Depth
3.4m
Maximum Dump Height
3.8m
Maximum Reach at Ground Level
5.8m
Capacities
Fuel Tank
51.9l
Hydraulic System
Auxiliary Standard Flow
64l/min
Auxiliary Pressure
205.95bar
Dimensions
Length
4,834mm
Overall Length in Travel Position
4,834mm
Width
1,753mm
Height
2,443mm
Height with Operator Cab
2,443mm
Features
Air Conditioning
Optional
Cab Enclosure
Optional
Cab Heater
Optional
Heater Air Conditioning
Optional
Radio
Optional
Tail Swing Type
Zero
Engine Shut Down
Standard
Auxiliary Hydraulics
Standard
Secondary Auxiliary Hydraulics
Optional
Hydraulic Hitch
Standard
Rubber Track
Standard
Selectable Auxiliary Hydraulic Flow
Standard
Angle Blade
N/A
