Bobcat S100 Skid Steer Loader
The Bobcat S100 skid steer loader is perfect for tight spaces. Small, durable and comfortable, this loader can handle all your construction and industrial needs.
Durable and reliable
Looking for a small, durable, and comfortable loader?
The Bobcat S100 skid steer loader is perfect for those tight spaces. With a lift capacity of over 450 kilograms, this loader can handle all your needs. It’s also very comfortable to use with an adjustable seat and controls that are easy to reach.
You’ll be able to take on any job with the Bobcat S100. This loader is perfect for industrial use with its durable construction and reliable performance. It’s the perfect tool for your business.
heading
copy
Play Video about Steve Pilcher Landscapes
Bobcat S100 Skid Steer Loader Specifications
Overview
Tipping Load
915kg
Engine Power
26.5kW (35.5hp)
Operating Weight
1,864kg
Lift Height
2,633mm
ROC
453kg
Engine
Make / Model
Kubota V1505
Fuel
Diesel
Cooling
Liquid
Power at 2300rpm (ISO 14396)
26.5kW (35.5hp)
Number of Cylinders
4
Displacement
1,498cc
Fuel Tank
45.0l
Performance
Tipping Load (ISO 14397-1)
915kg
Rated Operating Capacity (ISO 14397-1)
453kg
Pump Capacity
49.6l/min
System Relief at Quick Couplers
20.7MPa
Maximum Travel 2-Speed (SJC Controls)
13.4km/h
Maximum Travel 1-Speed (Manual Controls)
10.4km/h
Dimensions
Operatoring Height
3,306mm
Height with Operator Cab
1,877mm
Angle of Departure
25°
Ground Clearance
167mm
Wheelbase
818mm
Length without Attachment
2,263mm
Length with Standard Bucket
2,800mm
Rollback at Ground Position
26°
Dump Height with Standard Bucket
2,084mm
Height to Bucket Hinge Pin
2,633mm
Dump Reach at Maximum Height
412mm
Dump Angle at Maximum Height
43°
Rollback Fully Raised at Maximum Height
95°
Width Over Standard Bucket
1,270mm
Turning Radius with Standard Bucket
1,731mm
Track – Standard Tyres
967mm
Width Over Standard Tyres
1,167mm
Features
Bobcat Interlock Control System (BICS)
Standard
Hand and Foot Controls
Standard
Operator Cab Deluxe
Standard
Standard Seat
Standard
Seat Belt
Standard
Seat Bar
Standard
Bob-Tach Frame
Standard
276 x 8.50 – 15, 6-ply, Bobcat Heavy Duty Tyres
Standard
Auxiliary Hydraulics: Variable Flow / Maximum Flow
Standard
Operating Lights, Front and Rear
Standard
Lift-Arm Support
Standard
Parking Brake
Standard
Sparks Arrestor Muffler
Standard
Engine / Hydraulics System Shutdown
Standard
Automatically Activated Glow Plugs
Standard
Manual
Standard
Warranty: 24 Months or 2,000 Hours (Whichever Occurs First)
Standard
