Bobcat T590 Track Loader
The Bobcat T590 track loader is designed to handle space limitations and work in rough conditions, while still providing a high lift capacity of over 3 metres.
Handle rough terrain easily
Handle rough
terrain easily
If you’re looking for a loader that can handle rough terrain and has a high lifting capacity, the Bobcat T590 track loader is your perfect solution.
The Bobcat T590 is designed to handle space limitations and rough conditions, while still providing high lift capacity.
With a lifting height of over 3 metres, this loader is perfect for loading and unloading bricks, blocks, and other palletised materials.
heading
copy
Play Video about Steve Pilcher Landscapes
Bobcat T590 Track Loader Specifications
Overview
Tipping Load
2,773kg
Engine Power
49.2kW (66hp)
Operating Weight
3,632kg
Lift Height
3,023mm
ROC
907kg
Engine
Make / Model
Kubota V2607-Turbo
Fuel
Diesel
Cooling
Liquid
Power at 2600rpm (ISO 14396)
49.2kW (66hp)
Number of Cylinders
4
Displacement
2,615cc
Fuel Tank
138.2l
Performance
Tipping Load (ISO 14397-1)
2,773kg
Rated Operating Capacity (ISO 14397-1)
907kg
Pump Capacity
64l/min
Pump Capacity (with High Flow Option)
101.1l/min
System Relief at Quick Couplers
23.8 – 24.5 MPa
Maximum Travel Speed (High Range – Optional)
16km/h
Dimensions
Operating Height
3,901mm
Height with Operator Cab
1,976mm
Angle of Departure
27.8°
Ground Clearance
188mm
Ground Contact Length
1,402mm
Length without Attachment
2,657mm
Length with Standard Bucket
3,378mm
Rollback at Ground Position
30°
Dump Height with Standard Bucket
2,319mm
Height to Bucket Hinge Pin
3,023mm
Dump Reach at Maximum Height
887mm
Dump Angle at Maximum Height
42°
Rollback Fully Raised at Maximum Height
97°
Bucket Width A
1,727mm
Bucket Width B
1,880mm
Turning Radius with Standard Bucket
2,032mm
Width Over Tracks – 400mm
1,880mm
Features
Bobcat Interlock Control System (BICS)
Standard
Parking Brake
Standard
Deluxe Operator Cab – Includes Interior Cab Foam, Side, Top and Rear Windows, Deluxe Wire Harness, Dome Light and Electrical Power Port
Standard
Noise Reduction Kit
Standard
Operating Lights – Front and Rear
Standard
Deluxe Instrument Panel
Standard
Keyless Start with Password Capability
Standard
Suspension Seat
Standard
Seat Belt
Standard
Seat Bar
Standard
Hydraulic Bucket Positioning (Including On/Off Switch)
Standard
Tracks – Rubber – 320mm
Standard
Bob-Tach Frame
Standard
Cushioned Lift and Tilt Cylinders
Standard
Lift Arm Support
Standard
Engine / Hydraulics System Shutdown
Standard
Spark Arrester
Standard
Electrically Activated Proportional Front Auxiliary Hydraulics
Standard
Automatically Activated Glow Plugs
Standard
Auxiliary Hydraulics – Variable Flow / Maximum Flow
Standard
Machine IQ (Telematic)
Standard
Manual
Standard
CE Certification
Standard
Warranty – 24 Months or 2,000 Hours (Whichever Occurs First)
Standard
