Bobcat T66 Track Loader
The Bobcat T66 track loader goes where other equipment just can’t go. Enjoy increased lifting capabilities, powerful hydraulic performance, and fast cycle times.
Go where others can’t
Looking for a loader that can handle the most extreme working conditions?
The Bobcat T66 track loader is designed to tackle tough jobs where other equipment can’t. With increased lifting capabilities, powerful hydraulic performance and fast cycle times, this machine is perfect for the most challenging work environments.
You’ll appreciate the premium comfort of the Bobcat T66 track loader. It’s been designed with your needs in mind, so you can work longer and harder without feeling exhausted. Plus, its sleek design will make you stand out from the competition.
A loader that's tough as nails
The Bobcat T66 track loader has a new inline engine and direct-drive system, cast-steel lift arms, and improved cooling performance.
The vertical-lift-path Bobcat T66 has strong hydraulics and breakout forces, as well as quick cycle times and higher lifting capabilities.
The spacious cab has a sealed and pressurised environment, with options that include a heated air-ride seat, a clear-side enclosure, automatic heat and air conditioning, and a unique display with machine information and performance data.
Bobcat T66 Track Loader Specifications
Overview
Tipping Load
3,175kg
Engine Power
55.4kW (74hp)
Operating Weight
4,330kg
Lift Height
3,048mm
ROC
1,115kg
Engine
Make / Model
Bobcat V2 2.4L Turbo, Tier 4
Fuel
Diesel
Cooling
Liquid
Power at 2600rpm
55.4kW (74hp)
Torque at 1800rpm (SAE J1995)
283.9Nm
Number of Cylinders
4
Displacement
2,400cc
Fuel Tank
107.1l
Performance
Tipping Load (ISO 14397-1)
3,175kg
Rated Operating Capacity (ISO 14397-1)
1,115kg
Pump Capacity
64l/min
Pump Capacity (with High Flow Capacity)
101.8l/min
System Relief at Quick Couplers
23.8 – 24.5MPa
Maximum Travel Speed (High Range – Optional)
16.4km/h
Dimensions
Operating Height
3,910mm
Height with Operator Cab
2,044mm
Angle of Departure
25°
Ground Clearance
214mm
Ground Contact Length
1,380mm
Length without Attachment
2,717mm
Length with Standard Bucket
3,427mm
Rollback at Ground Position
30°
Dump Height with Standard Bucket
2,396mm
Height to Bucket Hinge Pin
3,048mm
Dump Reach at Maximum Height
933mm
Dump Angle at Maximum Height
37°
Rollback Fully Raised at Maximum Height
94°
Bucket Width
1,880mm
Turning Radius with Standard Bucket
2,104mm
Width Over Tracks – 400mm
1,880mm
Features
Bobcat Interlock Control System (BICS)
Standard
Parking Brake
Standard
Deluxe Operator Cab – Includes Interior Cab Foam, Side, Top and Rear Windows, Deluxe Wire Harness, Dome Light and Electrical Power Port
Standard
Noise Reduction Kit
Standard
Operating Lights – Front and Rear
Standard
Deluxe Instrument Panel
Standard
Keyless Start with Password Capability
Standard
Suspension Seat
Standard
Seat Belt
Standard
Seat Bar
Standard
Tracks – Rubber – 300mm
Standard
Bob-Tach Frame
Standard
Cushioned Lift and Tilt Cylinders
Standard
Lift Arm Support
Standard
Engine / Hydraulics System Shutdown
Standard
Spark Arrester
Standard
Automatically Activated Glow Plugs
Standard
Auxiliary Hydraulics – Variable Flow / Maximum Flow
Standard
Machine IQ (Telematic)
Standard
Manual
Standard
CE Certification
Standard
Warranty – 24 Months or 2,000 Hours (Whichever Occurs First)
Standard
