Bobcat T76 Track Loader
The Bobcat T76 track loader has been completely redesigned to meet the needs of today’s toughest jobsites. Perfect for anyone who wants a skid steer with tracks.
Built for today’s toughest jobsites
Built for today’s
toughest jobsites
The Bobcat T76 track loader has been completely redesigned to meet the needs of today’s toughest jobsites. With 54.5kW of horsepower and a vertical-lift-path, this loader is perfect for anyone who wants a skid steer with tracks.
You’ll appreciate the cast-steel lift arms and optimised lift arm linkage, which increase lift height and capacity. Plus, the direct-drive system and inline engine make this loader easy to operate.
The powerful track loader that can handle anything
The vertical-lift-path Bobcat T76 track loader is built to satisfy the hardest worksite requirements.
To boost lift height and capacity, the 54.5kW horsepower loader has an inline engine and direct-drive system, as well as cast-steel lift arms and an optimised lift arm linkage.
The loader’s low ground pressure track system allows operators to push through soft, sandy, damp, or muddy terrain.
You’ll love the loader’s strong hydraulics and breakout forces, as well as its quick cycle times and superior operator comfort.
The updated 5-link torsion suspension undercarriage gives a more pleasant ride on long working days, and improved features make routine maintenance simple.
Bobcat T76 Track Loader Specifications
Overview
Tipping Load
4,050kg
Engine Power
55.4kW (74hp)
Operating Weight
4,812kg
Lift Height
3,258mm
ROC
1,270kg
Engine
Make / Model
Bobcat V2 2.4L Turbo, Tier 4
Fuel
Diesel
Cooling
Liquid
Power at 2600rpm
55.4kW (74hp)
Number of Cylinders
4
Displacement
2,400cc
Fuel Tank
120l
Performance
Tipping Load (ISO 14397-1)
4,050kg
Rated Operating Capacity (ISO 14397-1)
1,270kg
Pump Capacity
87.6l/min
Pump Capacity (with High Flow Option)
114.7l/min
System Relief at Quick Couplers
23.8 – 24.5MPa
Maximum Travel Speed (High Range – Optional)
14.8km/h
Dimensions
Operating Height
4,252mm
Height with Operator Cab
2,079mm
Angle of Departure
27°
Ground Clearance
234mm
Ground Contact Length
1,526mm
Length without Attachment
2,893mm
Length with Standard Bucket
3,737mm
Rollback at Ground Position
30°
Dump Height with Standard Bucket
2,526mm
Height to Bucket Hinge Pin
3,258mm
Dump Reach at Maximum Height
1,014mm
Dump Angle at Maximum Height
37°
Rollback Fully Raised at Maximum Height
94°
Bucket Width
2,032mm
Turning Radius with Standard Bucket
2,301mm
Tracks – 450mm
1,531mm
Width Over Tracks – 450mm
1,880mm
Features
Selectable Joystick Controls (SJC)
Standard
Deluxe pressurised cab with HVAC
Standard
Adjustable Suspension Seat
Standard
3 Point Seat Belt
Standard
Seat Bar
Standard
Two Speed Travel
Standard
Deluxe Instrument Panel
Standard
Keyless Start with Password Capability
Standard
Suspension Seat
Standard
Seat Belt
Standard
Auxiliary Hydraulics – Variable Flow / Maximum Flow
Standard
High Flow Hydraulics
Standard
Dual Direction Bucket Positiong (Including On/Off Switch)
Standard
5″ Deluxe Instrumentation (Radio Ready)
Standard
Key Start
Standard
Back Up Alarm
Standard
Horn
Standard
LED Working Lights – Front and Rear
Standard
Parking Brake
Standard
Bob-Tach Attachment System
Standard
Bobcat Interlock Control System (BICS)
Standard
Engine / Hydraulics System Shutdown
Standard
Manual
Standard
Lift Arm Support
Standard
Spark Arrester
Standard
Tracks – Rubber – 450mm
Standard
Machine IQ (Telematic)
Standard
Warranty – 24 Months or 2,000 Hours (Whichever Occurs First)
Standard
