McCORMICK X5M CAB TRACTOR
The new McCormick X5M cab tractor combines technology, adaptability, and simplicity of handling.
The perfect blend of power and comfort
McCormick now offers the new X5M series of tractors, which are perfect for broad field and all-around farm work, for farmers looking for power and comfort.
There are two variants available: the X5.100M and X5.110M, which generate 95 and 102 hp of maximum power, respectively.
There are two trim levels available for the range: Premium, which is designed to entirely suit all of your demands, and Efficient, which offers entry-level specifications.
The small size of the new, more attractive design has not changed, but it provides the operator more visibility and comfort.
Hay now – you’re a rockstar
The new McCormick X5M combines technology, adaptability, and simplicity of handling.
Its exceptional features and performance make it the ideal tractor for agile transport, front loader barn and shed work, and light-duty open field work. It provides a meaningful response to customers’ requirements in farms – notably the hay sector.
McCORMICK X5M SPECIFICATIONS
standard
X5.100M
X5.110M
Engine
92.5 hp (68 kW) Perkins 110 4D engine, Tier 3, 4 cylinder turbo 4.4lt, dry element air cleaner, belt driven fan, fan guard, side lateral vertical exhaust
102 hp (74 kW) Perkins 110 4D engine, Tier 3, 4 cylinder turbo 4.4lt, dry element air cleaner, belt driven fan, fan guard, side lateral vertical exhaust
Transmission
12 x 12 transmission with powershift – 40kph, without creeper, 4WD hydra lock front axle with integrated brakes, electrohydraulic locking rear differential, heavy duty rear axle
48 x 16 Xtra shift (HML) transmission with powershift – 40kph, with creeper, 4WD hydra lock front axle with integrated brakes, electrohydraulic locking rear differential, heavy duty rear axle
PTO
Electrohydraulic rear engagement and wet disc clutch, 540 / 1,000 rpm, without groundspeed
Electrohydraulic rear engagement and wet disc clutch, 540 / 1,000 rpm, without groundspeed
Hydraulics
82l/min (52 + 30) litre hydraulic pump, three rear spool valved single / double acting (two kickout plus one float), predisposition for front loader, additional road lights
90l/min (60 + 30) litre high flow hydraulic pump, three rear spool valved single / double acting (two kickout plus one float), predisposition for front loader, additional road lights
Three Point Linkage
Rear lift with mechanical control Ergonomic Lift System (ELS), rear linkage cat.2 with quick hooks and mechanical top link, levelling rod, mechanically controlled for three- point lift arms
Rear lift with electronic control Ergonomic Lift System (ELS), rear linkage cat.2 with quick hooks and mechanical top link, external electronic lift controlled for three-point lift arms
Rear Hitch
Manual sliding hitch, turning EEC type plus EEC swinging drawbar
Manual sliding hitch, turning EEC type plus EEC swinging drawbar
Operator Area
Tiltable and telescopic steering wheel, pneumatic suspension seat with armrests and headrest, radio and sound system, air conditioning system, rear window wiper, external mirrors, cab with opening front windscreen, with Falling Objects Protective Structure (FOPS)
Tiltable and telescopic steering wheel, air suspension seat with armrests and headrest, instructor seat, radio and sound system, air conditioning system, rear window wiper, external mirrors, cab with opening front windscreen, with Falling Objects Protective Structure (FOPS)
Tyres
440/65R24 Front – 540/65R34 Rear
Rear fenders extensions
440/65R24 Front – 540/65R34 Rear
Rear fenders extensions
Weights and Dimensions
Maximum Length: 4,160mm
Minimum Width: 1,900mm
Wheel Base: 2,294mm
Height Over Cab: 2,620mm
Ground Clearance: 350mm
Weight without Ballast: 3,800kg
Maximum Length: 4,160mm
Minimum Width: 1,900mm
Wheel Base: 2,294mm
Height Over Cab: 2,620mm
Ground Clearance: 350mm
Weight without Ballast: 3,800kg
Miscellaneous
English operator’s manual, fuel tank protection, one rotating beacon light, without front weights
English operator’s manual, fuel tank protection, one rotating beacon light, without front weights
