Bobcat CT1025 Compact Tractor
The Bobcat CT1025 compact tractor packs a heap of power into a small frame. With four-wheel drive and 25hp, it’s the perfect workhorse for your small property.
Home » Tractor » Small Tractor » Bobcat CT1025 Compact Tractor
Small but powerful
Meet the perfect workhorse
The Bobcat CT1025 compact tractor is the perfect workhorse for your small property. With four-wheel drive and 26 horsepower, it’s powerful enough to tackle any job, yet small enough to manoeuvre easily around your land.
Whether you’re mowing a large yard, tilling the garden or hauling supplies, the Bobcat CT1025 will get the job done quickly and efficiently. And because it’s a Bobcat, you know it’s built to last.
Get a cracking deal on a Bobcat CT1025 before the end of September!
Do more with less
Get the power you need to operate a range of attachments and implements without losing the compact size and mobility you require to mow and do light-duty jobs around your property.
Enjoy the flexibility of a mid-PTO that allows you to combine two tools on one machine – one in the back, and either one in the front or utilise a mid-mount mower.
Expand your capabilities within a single machine. The rear PTO and Limited Category 1 three-point hitch provide you the option of using drag-behind or PTO-powered implements. And when the job calls for it, engage four-wheel drive for dependable traction.
Bobcat CT1025 Compact Tractor Specifications
overview
Horsepower
19.12kW (26hp)
Lift Capacity at 24″ behind Lift Point
317.51kg
PTO HP
15.07kW (20.5hp)
Transmission Type
2 Range Hydrostatic
Width
1,168mm
Turning Radius
2,530mm
Wheelbase
1,400mm
engine
Emissions Tier (EPA)
Tier 4
Horsepower
19.12kW (26hp)
Displacement
1,131cc
Number of Cylinders
3
Gross HP
19.12kW (26hp)
Engine Model
3C100LFH-U1
performance
Operating Weight
689.91kg
Travel Speed
16.6km/h
Travel Speed – Reverse
11.2km/h
3-Point Hitch
Category 1
3-Point Lift Control Type
Hydraulic Position Control System
Lift Capacity at 24″ behind Lift Point
317.51kg
Rear PTO System
Independent
Rear PTO – RPM
540rpm
PTO HP
15.07kW (20.5hp)
Mid PTO – RPM
2,200rpm
capacities
Fuel Tank
25.5l
hydraulic system
Implement Hydraulic Flow
26.12l/min
Total Hydraulic Flow
44.4l/min
Steering Hydraulic Flow
17.03l/min
dimensions
Length
2,541mm
Width
1,168mm
Height
2,237mm
Ground Clearance
177mm
Turning Radius
2,530mm
Wheelbase
1,400mm
Front Tyre Size
Front Industrial (AG, Turf) 18 x 8.5 – 10 4PR
Rear Tyre Size
Rear Industrial (AG, Turf) 26 x 12 – 12 4PR
drive systems
Brake Type
Wet Disc Type
Transmission Type
2 Range Hydrostatic
loader attatchment
Loader Lift Height
1,830mm
Lift Capacity @ 500mm Ahead of Bucket Pivot
318.42kg
Bucket Width
1,219mm
