Bobcat CT4055 Compact Tractor
The Bobcat CT4055 compact tractor is the biggest of the small tractors. Built for heavy-duty tasks on large properties, it has the horsepower to get it all done.
The powerful compact tractor that can handle the big jobs
The Bobcat CT4055 compact tractor is the perfect tractor for anyone who needs a lot of power in a small package. It’s got all the features you need to take on tough tasks, like mowing, grading driveways, and landscaping.
You’ll be able to do more with this tractor than ever before. You’ll appreciate its comfortable seat, easy-to-use controls, and great visibility. With 55 horsepower available and a durable design, it can handle anything you throw at it. Plus, it’s easy to operate so you can get the job done quickly and efficiently.
you get to do it all
The Bobcat CT4055 compact tractor has a manual synchro shuttle transmission for on-the-fly shifts and an open workstation with a Roll-Over Protective Structure for getting on and off the tractor fast during the day.
With greater horsepower to operate heavy-duty attachments and equipment, the 55 horsepower, turbo-charged Bobcat CT4055 can mow big properties, grade driveways, move heavy materials, and perform significant digging.
This heavy-duty work horse has a rear PTO, four-wheel drive, and a Category 1 three-point hitch, allowing you to use a variety of equipment to get more done on your property.
Bobcat CT4055 Compact Tractor Specifications
overview
Horsepower
40.45kW (55hp)
Lift Capacity at 24″ behind Lift Point
1,232kg
PTO HP
28.09kW (38.2hp)
Transmission Type
3 Range Hydrostatic
Width
1,730mm
Turning Radius
2,621mm
Wheelbase
1,810mm
engine
Emissions Tier (EPA)
Tier 4
Horsepower
40.45kW (55hp)
Displacement
2435cc
Number of Cylinders
4
Gross HP
40.45kW (55hp)
performance
Operating Weight
1,699kg
Travel Speed
29.7km/h
Travel Speed – Reverse
20.8km/h
3-Point Hitch
Category 1
3-Point Lift Control Type
Hydraulic Position Control System
Lift Capacity at 24″ behind Lift Point
1,232kg
Rear PTO System
Independent
Rear PTO – RPM
540rpm
PTO HP
28.09kW (38.2hp)
Mid PTO – RPM
2,000rpm
capacities
Fuel Tank
48l
hydraulic system
Implement Hydraulic Flow
36.34l/min
Total Hydraulic Flow
62.4l/min
Steering Hydraulic Flow
17.03l/min
dimensions
Length
3,307mm
Width
1,730mm
Height
2,270mm
Ground Clearance
368mm
Turning Radius
2,621mm
Wheelbase
1,810mm
Front Tyre Size
Front Industrial (AG, Turf) 10 – 16.5
Rear Tyre Size
Rear Industrial (AG, Turf) 14.9 – 24
drive systems
Brake Type
Wet Disc Type
Transmission Type
3 Range Hydrostatic
loader attatchment
Loader Lift Height
2,667mm
Lift Capacity @ 500mm Ahead of Bucket Pivot
814.2kg
Bucket Width
1,670mm
